Team Details
BIT-RACING
| University | Beijing Institute of Technology
CN Beijing IT short 730 |
|---|---|
| Location | Beijing, China |
| DV Team | Beijing Institute of Technology FSD |
| EV Team | Beijing Institute of Technology FSAE |
| Short Link | tid.fsg.one/445 |
Past Events
2012
Info
BIT Formula Racing Team was founded in June,2009, with more than 50 undergraduates and graduates who are interested in automobile technology. Our team holds the concept of passion, cooperation and innovation, aiming at improving research and creative abilities of college students. During the last two years, we designed and manufactured our first and second car with excellent performance in each competition. After obtaining the first championship of Formula Student China(FSC), BIT racing team achieved another peak at the 9th JSAE, winning the first place in acceleration, ranking 19th in general among 75 teams. The second generation of Black Shark brought us another championship in FSC 2011.
Car Specifications
General
| Frame Construction | 4130 tubular space frame |
|---|---|
| Material | 4130 tubular steel |
| Overall L | 2065 mm |
| Overall W | 1430 mm |
| Overall H | 1080 mm |
| Wheelbase | 1500 mm |
| Track (Fr) | 1255 mm |
| Track (Rr) | 1280 mm |
| Weight with 68kg driver (Fr) | 122 kg |
| Weight with 68kg driver (Rr) | 151 kg |
| Suspension | double wishbone |
| Tyres (Fr / Rr) | 152.4*66 R10, Hoosier LC0 |
| Wheels (Fr / Rr) | 6*10， 25.4 offset, 3 pc Al Rim |
| Drive Type | chain drive |
| Differential | Clutch pack limited slip, 162Nm preload, 1.5 bias ratio |
| Cooling | side mounted |
| Brake System | 4-Disk system, adjustable brake balance |
| Electronics | Multifunctional Steering Wheel |
Powertrain
| Engine | Honda CBR600F4i |
|---|---|
| Bore | 67 mm |
| Stroke | 42.5 mm |
| Cylinders | 4 |
| Displacement | 599 ccm |
| Compression Ratio | 12:1 : 1 |
| Fuel System | fuel injection |
| Fuel | 98 octane |
| Max Power Design | 10500 rpm |
| Max Torque Design | 7500 rpm |
