Team Details

Racing Power Münster e.V.

University	FH Münster DE Münster UAS short 1453
Location	Münster, Germany
Homepage	https://teamrpm.de
Social Media
Short Link	tid.fsg.one/1414
Event Details	car 91 - withdrawn

Team Description

We are a relatively new team to Formula Student. Established towards the end of 2022, we spent the whole of 2023 laying the ground work for a debut in the 2024 season. With the knowledge gathered in these first years, we have now returned with our second car: the RPX-02. Close to 100 kilograms lighter than its predecessor and powered by two Emrax 188 motors with a dual chain drive system, we aim to make a significant leap in performance compared to our first ever car, the seriously obese RPX-01.

Past Events

2024

Car #80

Info

29x

Our newly founded team consists of 35 students from various departments at Münster University of Applied Sciences. We have set ourselves the goal of building our first racing car - the RPX-01. We want to take part in the first events with the all-electric car in 2024.

Engineering Design Priorities:

teamrpm RPX-01 racingpowermuenster uasmuenster mission2024 campussteinfurt

Car Specifications

General

Frame Construction	Steel frame
Material	/
Overall L	3046 mm
Overall W	1400 mm
Overall H	1200 mm
Wheelbase	1600 mm
Track (Fr)	1200 mm
Track (Rr)	1150 mm
Weight with 68kg driver (Fr)	143 kg
Weight with 68kg driver (Rr)	245 kg
Suspension	Double unequal length A-Arm. Push rod actuated horizontally oriented spring and damper
Tyres (Fr / Rr)	20.0X7.0-13, Slick - G-19
Wheels (Fr / Rr)	SUPERLEGG.COMP. 7x13 ET 22 4x100 SPECIAL
Drive Type	/
Differential	/
Cooling	/
Brake System	/
Electronics	/

Powertrain

Number of Motors	2
Motor Location	Rear right & left
Max Motor Power (per motor)	7kW kW
Motor Type	EMRAX 188
Max Motor RPM (highest)	7000 rpm
Motor Controller	Bamocar
Max System Voltage	490 V
Electrode Materials	/
Combined Accumulator Capacity	7,6kWh kWh
Transmission Ratio (Primary)	/ : 1
Transmission Ratio (Secondary)	/ : 1
