Team Details
TU Brno Racing
| University | Brno University of Technology
CZ Brno TU short 692 |
 |
|---|---|---|
| Location | Brno, Czech Republic | |
| Homepage | https://tubrnoracing.cz/ | |
| Social Media | ||
| CV Team | TU Brno Racing | |
| Short Link | tid.fsg.one/1116 | |
| Event Details | car 74 - withdrawn | |
Team Description
We are a Czech Formula Student team that has been competing since 2010. We had designed, manufactured, tested, and raced with 15 Dragons at 33 races and got 68 podiums. In this year, we are planning to project all the experience from 10 years of building combustion and 4 years of building electric vehicles to create our most powerful car: Dragon e5! This electric beast would also be carried by a huge innovation, which is an all-wheel-drive concept!
Past Events
2024
Info
94x
Since 2010, the TU Brno Racing team has successfully designed and built 13 Formula Student cars, 10 were powered by combustion engines. We are thrilled to present our latest achievement: the Dragon e4, fourth electric formula car! The construction of this remarkable vehicle was carried out by 50 talented students from 4 faculties of Brno University of Technology. With the Dragon e4, we have set our sights high, aiming to achieve the best results in the history of our team.
Car Specifications
General
| Frame Construction | ull CFRP sandwich monocoque with tubular steel mainhoop and aluminium fronhoop |
|---|---|
| Material | Toray T800 twill + DT120 epoxy resin, Toray M46J UD + DT120 epoxy resin |
| Overall L | 2926 mm |
| Overall W | 1438 mm |
| Overall H | 1160 mm |
| Wheelbase | 1528 mm |
| Track (Fr) | 1200 mm |
| Track (Rr) | 1170 mm |
| Weight with 68kg driver (Fr) | 242 kg |
| Weight with 68kg driver (Rr) | 242 kg |
| Suspension | Double wishbone CFRP A-arms with unequal length, Pull and Push rod Roll-Heave |
| Tyres (Fr / Rr) | 16.0x7.5 R10, Hoosier LC0 / 16.0x7.5 R10, Hoosier LC0 |
| Wheels (Fr / Rr) | 8.0x10, 41 mm offset, custom CFRP + Al / 8.0x10, 41 mm offset, custom CFRP + Al |
| Drive Type | Stepped planetary gearbox |
| Differential | n/a |
| Cooling | Twin behind rear axle mounted radiators with thermostatic controlled electric fan |
| Brake System | 4-Disk system, self developed rotors with 186(front), 180(rear) diameter, BREMBO caliperse |
| Electronics | Concentric twisted harnesses with Autosport connectors, |
Powertrain
| Number of Motors | 2 |
|---|---|
| Motor Location | Rear Right, Rear Left |
| Max Motor Power (per motor) | 35,4 kW, 35,4 kW kW |
| Motor Type | RR, RL: Fischer elektromotoren TI085 |
| Max Motor RPM (highest) | RR, RL: 20000 rpm |
| Motor Controller | Fully-custom inverter |
| Max System Voltage | 600V V |
| Electrode Materials | LiCoO2 |
| Combined Accumulator Capacity | 8 kWh kWh |
| Transmission Ratio (Primary) | 1:12 : 1 |
| Transmission Ratio (Secondary) | n/a : 1 |
2023
Info
57x
Since 2010, the TU Brno Racing team has successfully designed and built 13 Formula Student cars, 10 were powered by combustion engines. We are thrilled to present our latest achievement: the Dragon e3, third electric formula car! The construction of this remarkable vehicle was carried out by 50 talented students from 4 faculties of Brno University of Technology. With the Dragon e3, we have set our sights high, aiming to achieve the best results in the history of our team.
Engineering Design Priorities:
Fastest 2WD car
Lightest race car
Fully-custom inverter
Functional driverless
Cornering optimization
Car Specifications
General
| Frame Construction | Full CFRP sandwich monocoque with tubular steel mainhoop and aluminium fronhoop |
|---|---|
| Material | Prepreg fiber: Toray T300 + EP4.5 resin, Toray T800 UD + EP4.5S resin |
| Overall L | 2926 mm |
| Overall W | 1438 mm |
| Overall H | 1160 mm |
| Wheelbase | 1528 mm |
| Track (Fr) | 1200 mm |
| Track (Rr) | 1170 mm |
| Weight with 68kg driver (Fr) | 119 kg |
| Weight with 68kg driver (Rr) | 122 kg |
| Suspension | Double wishbone CFRP A-arms with unequal length, Pull rod,Roll-Heave decouplned suspension |
| Tyres (Fr / Rr) | 16.0x7.5 R10, Hoosier LC0 / 16.0x7.5 R10, Hoosier LC0 |
| Wheels (Fr / Rr) | 8.0x10, 41 mm offset, custom CFRP + Al / 8.0x10, 41 mm offset, custom CFRP + Al |
| Drive Type | Stepped planetary gearbox |
| Differential | n/a |
| Cooling | Twin behind rear axle mounted radiators with thermostatic controlled electric fan |
| Brake System | 4-Disk system, self developed rotors with 186(front), 180(rear) diameter, BREMBO caliperse |
| Electronics | Concentric twisted harnesses with Autosport connectors, |
Powertrain
| Number of Motors | 2 |
|---|---|
| Motor Location | Rear Right, Rear Left |
| Max Motor Power (per motor) | 35,4 kW kW |
| Motor Type | RR, RL: Fischer elektromotoren TI085 |
| Max Motor RPM (highest) | RR, RL: 20000 rpm |
| Motor Controller | Fully-custom inverter |
| Max System Voltage | 600V V |
| Electrode Materials | LiCoO2 |
| Combined Accumulator Capacity | 8 kWh kWh |
| Transmission Ratio (Primary) | 1:12 : 1 |
| Transmission Ratio (Secondary) | n/a : 1 |
Driverless System
| Processing unit(s) | Intel® Core™ i9-10900T, Nvidia GTX 1660 Ti Mobile |
|---|---|
| Floating Point Operations Per Second of all processing units that are working for the DV system | 5344.00 GigaFLOPS |
| Power consumption of all processing units that are working for the DV system | 85.00 W |
| Camera(s) | 2 cameras, 15m range with 5% accuracy, 110° opening angle, ZED stereoscopic cameras unit |
| Radar sensor(s) | none |
| Lidar sensor(s) | 1 lidar, 100m range, 133° opening angle, Valeo Scala 2 development unit |
| Other sensors | VectorNav Dual Antenna GNSS-Aided Inertial Navigation System |
| Highlights of the DV system | Our autonomous system is built on the Robot operating system platform. Cones are detected using lidar and stereoscopic cameras. Cone positions from cameras are calculated using a depth map built from the camera image. We use SLAM algorithm for the localization of our vehicle on the map. Motors and steering are controlled using PID regulators. |
FS past achievements due to World Ranking Data Base
| Date | Event | Teams | Rank | BP | CM | ED | SP | DV SP | AC | DV AC | AX | EN | EF | Pe | Total |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2025.08 | 13 |
3. |
7. |
7. |
3. |
5. |
- |
5. |
- |
6. |
3. |
4. |
0.00 |
467.64 |
|
| 2025.08 | 27 |
6. |
21. |
3. |
3. |
6. |
- |
10. |
- |
8. |
- |
- |
0.00 |
337.09 |
|
| 2025.08 | 53 |
24. |
33. |
33. |
14. |
17. |
- |
21. |
- |
16. |
- |
- |
0.00 |
338.55 |
|
| 2024.08 | 79 |
19. |
58. |
31. |
23. |
14. |
- |
35. |
- |
39. |
12. |
16. |
0.00 |
440.18 |
|
| 2024.08 | 47 |
5. |
27. |
39. |
11. |
8. |
- |
15. |
- |
5. |
5. |
9. |
-10.00 |
602.44 |
|
| 2024.07 | 38 |
6. |
22. |
31. |
9. |
8. |
- |
12. |
- |
11. |
4. |
8. |
0.00 |
582.60 |
|
| 2023.08 | 70 |
10. |
52. |
57. |
5. |
14. |
- |
25. |
- |
23. |
8. |
6. |
0.00 |
443.33 |
|
| 2023.08 | 35 |
2. |
13. |
9. |
2. |
3. |
- |
10. |
- |
2. |
3. |
2. |
0.00 |
768.22 |
|
| 2023.08 | 31 |
5. |
29. |
8. |
2. |
- |
- |
- |
- |
4. |
3. |
2. |
0.00 |
702.80 |
|
| 2022.08 | 25 |
9. |
3. |
2. |
2. |
2. |
- |
16. |
- |
6. |
- |
- |
0.00 |
463.60 |
|
| 2022.08 | 33 |
3. |
23. |
11. |
1. |
4. |
- |
17. |
- |
6. |
3. |
2. |
0.00 |
688.53 |
|
| 2022.07 | 19 |
9. |
8. |
5. |
2. |
- |
- |
- |
- |
8. |
- |
- |
0.00 |
288.50 |
|
| 2021.08 | 14 |
2. |
1. |
4. |
5. |
4. |
- |
6. |
- |
4. |
3. |
1. |
0.00 |
506.41 |
|
| x 13 | |||||||||||||||
DV Results
| Date | Event | Teams | Rank | BP | CM | ED | DV SP | DV AC | AX | EN | EF | Pe | Total |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2023.08 | 9 |
7. |
- |
- |
- |
- |
- |
- |
- |
- |
0.00 |
0.00 |
|
| x 1 | |||||||||||||
